Zocon Tipping Trailers

Z045

Size: Tonnes

4.5

Max Weight: kg

5700

Loading Capacity: kg

4500

Bucket Dimensions: cm

340 x 180 x 40

Weight Tipping Trailer: kg

1200

Power Demand: HP

45 - 75

Height Loading Platform: cm

96

Tipping Angle

50°

Z045 BASIC EQUIPMENT

Self closing backdoor

Under and upper drawbar

Automatic lock system backdoor

Frame and side boards galvanised

Removable side boards

Tipping system 1 side

Lighting

Thickness bottom: 4mm

Support wheel

Thickness sideboards: 2mm

Turnable hitch 45

Z080

Size: Tonnes

 8

Max Weight: kg

10,300

Loading Capacity: kg

8000

Bucket Dimensions: cm

450 x 220 x 60

Weight Tipping Trailer: kg

2300

Power Demand: HP

60

Height Loading Platform: cm

106

Tipping Angle

50°

Z080 BASIC EQUIPMENT

Automatic Hydraulic lock system backdoor

Tyres 11.5/80-15

Mechanical lock systems sideboards

Under and upper drawbar

Lighting

Upper-under frame and load platform galvanised

Support

Removable side boards

Turnable hitch 45

Thickness bottom: 4mm

One side tipping (backwards)

Thickness sideboards: 2mm

Tandem (bogie)

Z100

Size: Tonnes

10

Max Weight: kg

12,700

Loading Capacity: kg

10,000

Bucket Dimensions: cm

450 x 220 x 60

Weight Tipping Trailer: kg

2700

Power Demand: HP

80

Height Loading Platform: cm

106

Tipping Angle

50°

Z100 BASIC EQUIPMENT

Automatic

Tandem (bogie, parabolic suspension)

Hydraulic lock system backdoor

Tyres 15/55x17

Lighting

Under and upper drawbar  Upper-under frame and load platform galvanised

Support

Removable side boards

Turnable hitch 50

Thickness bottom: 4mm

One side tipping (backwards)

Thickness sideboards: 2mm

4 wheel braking
